General Specifications
Platform
Boxed Processor
Product Family
AMD Ryzen™ Processors
Product Line
AMD Ryzen™ 3 Desktop Processors with Radeon™ Vega Graphics
# of CPU Cores
4
# of Threads
4
Max. Boost Clock
Up to 3.7GHz
Base Clock
3.5GHz
Total L1 Cache
384KB
Total L2 Cache
2MB
Total L3 Cache
4MB
Default TDP
65W
AMD Configurable TDP (cTDP)
46-65W
Processor Technology for CPU Cores
14nm FinFET
Unlocked for Overclocking
Yes
CPU Socket
AM4
Thermal Solution (PIB)
Wraith Stealth
Thermal Solution (MPK)
Wraith Stealth
Max. Operating Temperature (Tjmax)
95°C
Launch Date
02/12/2018
*OS Support
Windows 10 - 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.
Connectivity
PCI Express® Version
PCIe® 3.0 x8
System Memory Type
DDR4
Memory Channels
2
System Memory Specification
Up to 2933MHz
Graphics Capabilities
Graphics Model
Radeon™ Vega 8 Graphics
Graphics Core Count
8
Graphics Frequency
1100 MHz
Product IDs
Product ID Boxed
YD2200C5FBBOX
Product ID Tray
YD2200C5M4MFB
Product ID MPK
YD2200C5FBMPK
Key Features
Supported Technologies
AMD Software: Adrenalin Edition
AMD SenseMI Technology
AMD VR Ready Processors
AMD Ryzen™ Master Utility
Enmotus FuzeDrive™ for AMD Ryzen™
AMD FreeSync™ Technology
