Graphics Processor
GPU Name
GF106
GPU Variant
GF106-250-KA-A1
Architecture
Fermi
Foundry
TSMC
Process Size
40 nm
Transistors
1,170 million
Die Size
238 mm²
Graphics Card
Release Date
Sep 13th, 2010
Generation
GeForce 400
Predecessor
GeForce 200
Successor
GeForce 500
Production
End-of-life
Launch Price
129 USD
Bus Interface
PCIe 2.0 x16
Reviews
80 in our database
Clock Speeds
GPU Clock
783 MHz
Shader Clock
1566 MHz
Memory Clock
902 MHz
3.6 Gbps effective
Memory
Memory Size
1024 MB
Memory Type
GDDR5
Memory Bus
128 bit
Bandwidth
57.73 GB/s
Render Config
Shading Units
192
TMUs
32
ROPs
16
SM Count
4
L1 Cache
64 KB (per SM)
L2 Cache
256 KB
Theoretical Performance
Pixel Rate
6.264 GPixel/s
Texture Rate
25.06 GTexel/s
FP32 (float) performance
601.3 GFLOPS
FP64 (double) performance
50.11 GFLOPS (1:12)
Board Design
Slot Width
Dual-slot
Length
210 mm
8.3 inches
Width
111 mm
4.4 inches
TDP
106 W
Suggested PSU
300 W
Outputs
2x DVI
1x mini-HDMI 1.3a
Power Connectors
1x 6-pin
Board Number
P1060
Graphics Features
DirectX
12 (11_0)
OpenGL
4.6
OpenCL
1.1
Vulkan
N/A
CUDA
2.1
Shader Model
5.1
